Heat Resistant Conveyor Belt (Indus)

Product Features

  • Standard Widths – 2200mm(86″) | Upto 5500mm(197″) Available in Longitudinal Joint
  • Type of Fabric – NN/EP/PP
  • Breaker Fabric Ply – Optional / as per customer requirement
  • Standard Belt Rating – 200 N/mm (110 PIW) to 3200 N/mm (1800 PIW)
  • No. of Ply’s – 1 Ply to 8 Ply
  • Rubber Cover Thickness – 1mm (1/25”) to 25mm (1”)
  • Colour – Black
  • Edge – Cut Edge / Moulded Edge
  • Splicing Method – Hot / Cold / Mechanical
  • Single Roll Length – Standard Length : 300 meters (1000’) | Up to 1000 meters (3300’) depending upon total belt thickness
  • Standard Packing – Wrapping in HDPE sheets with Strapping. | (Wooden Crate / Metal Crate packing is available on request)
  • Belt Identification Number – A unique BIN (Belt identification number) at every 10 meters (33’)
Categories: ,

Description

Indus Super Thermo Range of Cover Grades

Cover Grades Applicable Standards Type Of Polymer Resistance to Temperature Min. Tensile Strength
(MPa)		 Min. Elongation at Break
(%)		 Max. Abrasion Loss
(mmÂł)		 Application Areas % Change in Tensile & Elongation at Break after heat ageing
HR (T-1) IS-1891 Part 2 NR/SBR 125 ÂșC / 257 ÂșF for lumps & 100 ÂșC / 212ÂșF for fines 15 450 150 Suitable to convey hot coke, foundry sand, iron pellets. sintered ore, hot limestone, cement clinker, soda ash, etc. -25% & -40% @ 100 ÂșC for 72 Hrs
SHR (T-2) IS-1891 – Part 2 SBR 150 ÂșC / 302 ÂșF for lumps & 125 ÂșC / 257 ÂșF for fines 15 450 150 -35 & -50% @ 125 ÂșC
for 72 Hrs
SHAR Indus SBR 150 ÂșC / 302 ÂșF for lumps & 125 ÂșC / 257 ÂșF for fines 15 350 100 Suitable for high abrasive hot materials. -25 & -50% @ 125 ÂșC
for 72 Hrs
UHR Indus EPDM 200 ÂșC /392 ÂșF for lumps
&
180 ÂșC /356 ÂșF for fines		 15 450 150 Suitable for extremely hot material such as cement clinker, sintered Ore, etc. -15% & -35% @ 150 ÂșC
for 72 Hrs
SUHR Indus EPDM / EPM 250 ÂșC / 482ÂșF for lumps
&
180 ÂșC / 356 ÂșF for fines		 13 450 150 -10% & -30% @ 150 ÂșC
for 72 Hrs
HR-OR* Indus Blend of NBR & SBR 125 ÂșC / 257 ÂșF for lumps
&
100 ÂșC / 212 ÂșF for fines		 12 350 150 Suitable to convey hot oily materials. -25% & -40% @ 100 ÂșC
for 72 Hrs

*Specifications are subject to change without notice.
