Oil, Grease & Fat Resistant Conveyor Belt (Indus)

Product Features

  • Standard Widths – 2200mm(86″) | Upto 5000mm(197″) Available in Longitudinal Joint
  • Type of Fabric – NN/EP/PP
  • Breaker Fabric Ply – Optional / as per customer requirement
  • Standard Belt Rating – 200 N/mm (110 PIW) to 3200 N/mm (1800 PIW)
  • No. of Ply’s – 1 Ply to 8 Ply
  • Rubber Cover Thickness – 1mm (1/25”) to 25mm (1”)
  • Colour – Black
  • Edge – Cut Edge / Moulded Edge
  • Splicing Method – Hot / Cold / Mechanical
  • Single Roll Length – Standard Length : 300 meters (1000’) | Up to 1000 meters (3300’) depending upon total belt thickness
  • Standard Packing – Wrapping in HDPE sheets with Strapping. | (Wooden Crate / Metal Crate packing is available on request)
  • Belt Identification Number – A unique BIN (Belt identification number) at every 10 meters (33’)
Categories: ,

Description

Indus Super Click Range of Cover Grades

Cover Grades Applicable Standards Min. Tensile Strength (MPa) Min. Elongation at Break (%) Max. Abrasion Loss
(mm³)		 Maximum Swelling in Fuel B @ 72 Hrs (%) Application Areas
OR IS-1891-Part 3 12 250 150 75 Suitable to convey oily & greasy materials such as oily vegetables, oily wooden chips ,etc.
G DIN ISO 14890 12 250 150 75
MOR INDUS 15 400 150 60 Suitable to convey moderately oily materials like oil coated food grains, seeds, sand , etc.
HOR INDUS 17 400 130 35 Suitable to convey oil treated fertilizers, crude, petroleum products.
OAR* INDUS 17 400 100 35 Suitable to convey oil & abrasive materials.
OR-FR* INDUS 15 350 175 55 Suitable to convey oil coated flammable materials for over ground application.
OR-HR* INDUS 12 350 150 55 Suitable to convey hot oily materials for 125 ºC / 248 ºF for lumps & 100 ºC / 212ºF for fines.
OR-HR-FR* INDUS 12 350 175 55 Suitable to convey hot & oily materials having fire hazard for over ground application.

*Specifications are subject to change without notice.
