General Purpose Impact & Abrasion Resistance Conveyor Belt (Indus)

Product Features

  • Standard Widths – 2200mm(86″) | Upto 5500mm(197″) Available in Longitudinal Joint
  • Type of Fabric – NN/EP/PP/EE
  • Breaker Fabric Ply – Optional / as per customer requirement
  • Standard Belt Rating – 200 N/mm (110 PIW) to 3200 N/mm (1800 PIW)
  • No. of Ply’s – 1 Ply to 8 Ply
  • Rubber Cover Thickness – 1mm (1/25”) to 25mm (1”)
  • Colour – Black
  • Edge – Cut Edge / Moulded Edge
  • Splicing Method – Hot / Cold / Mechanical
  • Single Roll Length – Standard Length : 300 meters (1000’) | Up to 1000 meters (3300’) depending upon total belt thickness
  • Standard Packing – Wrapping in HDPE sheets with Strapping. | (Wooden Crate / Metal Crate packing is available on request)
  • Belt Identification Number – A unique BIN (Belt identification number) at every 10 meters (33’)
Categories: ,

Description

Indus Super Brute Range of Cover Grades

Cover Grades Applicable Standards Min. Tensile Strength
(MPa)		 Min. Elongation at Break
(%)		 Max. Abrasion Loss
(mm³)		 Application Areas
DIN-Z DIN 22102 15 350 250 Suitable to convey less abrasive material such as soda, earth, smooth sand, ground cement, clay, slaked lime, charcoal, grain flour, dry inert powder, wood chips & dry pulps under standard working conditions.
RMA-2 RMA 14 400 200
ISO-L ISO 10247 15 350 200
IS-N-17 IS 1891 17 400 200
AS-N AS 1332 17 400 200
ARPM RMA-2 ARPM 14 400 175
SANS-N SANS 1173 17 400 150 Suitable to convey moderately sharp & abrasive material such as rubble, sharp sand ,lump & powder of superphosphate, bone, coal, ashes, unslaked lime, ungrounded cement under average working conditions.
RMA-1 RMA 17 400 150
DIN Y DIN 22102 20 400 150
SANS-C SANS 1173 20 400 150
IS-M-24 IS 1891 24 450 150
ARPM RMA-1 ARPM 17 400 125
AS-M AS 1332 24 450 125
ISO-H ISO 10247 24 450 120
SANS-M SANS 1173 25 450 120
DIN X DIN 22102 25 450 120
ISO-D ISO 10247 18 400 100 Suitable to convey highly abrasive materials such as lumps of highly abrasive metal ores.
DIN-W /HAR DIN 22102 18 400 90
SANS-A SANS 1173 18 400 70 Suitable to convey highly abrasive material such as combination of highly abrasive lumps & fines.
AS-A / SAR AS 1332 17 400 70
Crusher+ Indus 20 450 70 Specially formulated cover to provide the best combination of tensile strength and abrasion resistance. It is specifically designed for primary crusher units to handle high impact and high abrasive material enabling maximum possible output.
Crusher++ Indus 20 400 50
UAR Indus 18 400 40 Specially formulated cover for carrying extremely high abrasive material in form of granules & fines.
Rip & Tear Resistant
(RTR-A)		 Indus 26 450 100 Suitable to convey a combination of high impact, high cut, high gouge & high rip material such as extremely sharp lumps & high impact materials.
Rip & Tear Resistant
(RTR-B)		 Indus 28 500 150

*Specifications are subject to change without notice.
