Fire Resistant Conveyor Belt (Indus)

Product Features

  • Standard Widths – 2200mm(86″) | Upto 5000mm(197″) Available in Longitudinal Joint
  • Type of Fabric – NN/EP/PP
  • Breaker Fabric Ply – Optional / as per customer requirement
  • Standard Belt Rating – 200 N/mm (110 PIW) to 3200 N/mm (1800 PIW)
  • No. of Ply’s – 1 Ply to 8 Ply
  • Rubber Cover Thickness – 1mm (1/25”) to 25mm (1”)
  • Colour – Black
  • Edge – Cut Edge / Moulded Edge
  • Splicing Method – Hot / Cold / Mechanical
  • Single Roll Length – Standard Length : 300 meters (1000’) | Up to 1000 meters (3300’) depending upon total belt thickness
  • Standard Packing – Wrapping in HDPE sheets with Strapping. | (Wooden Crate / Metal Crate packing is available on request)
  • Belt Identification Number – A unique BIN (Belt identification number) at every 10 meters (33’)
Categories: ,

Description

Indus Super Blaze Range of Cover Grades

Cover Grades Applicable Standards Min. Tensile Strength (MPa) Min. Elongation at Break (%) Max. Abrasion Loss (mm³) Application Areas
FR-IS IS-1891-Part 5 17 400 175 Moderate resistance to flame propagation. Suitable to convey coal, minerals & ore for over ground application.
FR-ISO 340 / DIN-K ISO-340-2013 17 400 175 Good resistance to flame propagation and has low burning rate. Suitable to convey coal, minerals & ore for over ground application.
FR-ISO 340 / DIN-S ISO-340-2013 17 400 175 Very good resistance to flame propagation and has low burning rate. Suitable for over ground for high risk materials and Underground for low risk application.
FR-CAN-CSA CAN-CSA-M422-2014 17 400 175 Moderate resistance to flame propagation. Suitable to convey coal, minerals & ore for over ground application.
FR-MSHA-2G CFR-30- Part 18 17 400 175
FR-MSHA CFR-30-
Part 14/75		 15 400 200 Very good resistance to flame propagation and has low burning rate. Suitable to convey coal, minerals & ore for underground application.
FR-AS-S AS 4606-2012 18 400 120
FR-AS-F AS 1332-2000 17 400 175 Very good resistance to flame propagation and has low burning rate. Suitable for over ground for high risk materials and underground for low risk application.
FR-SANS-F SANS-971-2013 17 400 175
FR-SANS-FRX SANS-971-2013 14 400 175 Very good resistance to flame propagation and has low burning rate. Suitable to convey Coal, minerals & ore for underground application.
FR-SAR* INDUS 17 400 110 Combination of good resistance to flame propagation & good abrasion resistance. Suitable to convey Coal, minerals & ore for over ground application.
FR-OR* INDUS 15 400 175 Combination of good resistance to flame propagation & moderate oil resistance. Suitable to convey oil coated flammable materials for over ground application.
FR-HR-OR* INDUS 12 350 200 Combination of good resistance to flame propagation & heat resistance & moderate oil resistance. Suitable to convey Hot & oily materials having fire hazard for over ground application.
FR-HF* INDUS 12 400 200 Halogen free belt with low smoke properties.

*Specifications are subject to change without notice.
