NN/EP/PP/EE Conveyor Belts (Indus)

Standard Widths – 2200mm(86″) | Upto 5500mm(197″) Available in Longitudinal Joint
Type of Fabric – NN/EP/PP/EE
Breaker Fabric Ply – Optional / as per customer requirement
Standard Belt Rating – 200 N/mm (110 PIW) to 3200 N/mm (1800 PIW)
No. of Ply’s – 1 Ply to 8 Ply
Rubber Cover Thickness – 1mm (1/25”) to 25mm (1”)
Colour – Black
Edge – Cut Edge / Moulded Edge
Splicing Method – Hot / Cold / Mechanical
Single Roll Length – Standard Length : 300 meters (1000’) | Up to 1000 meters (3300’) depending upon total belt thickness
Standard Packing – Wrapping in HDPE sheets with Strapping. | (Wooden Crate / Metal Crate packing is available on request)
Belt Identification Number – A unique BIN (Belt identification number) at every 10 meters (33’)

Description

Indus Covers are engineered rubber layers applied on top & bottom of the carcass.
We pay great attention to decide the Cover grade, quality and thickness as these factors are directly attributable to the longevity of the belt’s service life.
A specific cover formulation used in an individual belt construction is determined by the material to be carried and the environment in which the belt will operate.
The Covers can be manufactured with texture or profiles to prevent roll back of material in case of higher inclination

Top Rubber Cover’s main function is to protect the carcass and help extend its service life.
At Indus Belts, our rubber technologists have developed a variety of cover grades which have properties such as Resistance to Wearing, Tearing, Cutting, Gouging, Impact, Heat & Cold, Fire, Oil & Chemical.

Indus Bottom Rubber Cover has good abrasion resistance as it is this part of the belt which is in constant contact with the drive pulley to transmit the power to the belt.
Indus Bottom Rubber Cover also comes in specially formulated Low Rolling Resistant property which helps in lower consumption of power/energy required to run a belt on a system.

Skim Rubber is a thin layer made with specially engineered polymer grades & chemicals with high adhesion properties to provide excellent bonding strength between skim & fabric plies & between skim inter layers along the length & across the width of the belt.
For specific applications, we have formulated special skim compounds to offer application specific properties like resistance to heat, fire, oil & chemical while maintaining the excellent bonding properties which are utmost important for a carcass to perform its function.

Fabric is one of the most critical component used in the manufacturing of a textile conveyor belt.
We procure high quality textile fabric from only reputed fabric manufacturers, who have a proven track record to deliver high performance high quality conveyor belt textile fabrics.
Our Quality checks ensures that the sourced fabric has important properties such as Strength, Elongation, Load Bearing Capacity, Flexibility, Troughability, Impact Resistance, Dimensional Stability and Transverse Stiffness depending upon the quality and construction of the fabric being used in the manufacturing of a conveyor belt.
