Frost & Cold Resistant Conveyor Belt (Indus)

Product Features

  • Standard Widths – 2200mm(86″) | Upto 5000mm(197″) Available in Longitudinal Joint
  • Type of Fabric – NN/EP/PP
  • Breaker Fabric Ply – Optional / as per customer requirement
  • Standard Belt Rating – 200 N/mm (110 PIW) to 3200 N/mm (1800 PIW)
  • No. of Ply’s – 1 Ply to 8 Ply
  • Rubber Cover Thickness – 1mm (1/25”) to 25mm (1”)
  • Colour – Black
  • Edge – Cut Edge / Moulded Edge
  • Splicing Method – Hot / Cold / Mechanical
  • Single Roll Length – Standard Length : 300 meters (1000’) | Up to 1000 meters (3300’) depending upon total belt thickness
  • Standard Packing – Wrapping in HDPE sheets with Strapping. | (Wooden Crate / Metal Crate packing is available on request)
  • Belt Identification Number – A unique BIN (Belt identification number) at every 10 meters (33’)
Categories: ,

Description

Cold & Frost Resistant Conveyor Belts

Indus Frost Resistant Conveyor Belts are manufactured using special cover properties which are resistant to cold and freezing temperature while maintaining properties such as resistance to abrasion, impact & gouging, oil & fire. At temperatures below -15°C, rubber covers start to lose their elasticity. Due to the loss of elasticity, the rubber hardens and becomes brittle leading to the cracking of the surface of the conveyor belt. Indus Frost Resistant Covers are made with specially selected polymers which have an inherent ability to maintain elasticity at extremely low temperatures. These polymers mixed with speciality chemicals enables these covers to function even in the harshest and most extreme environmental conditions.

Indus Frost Resistant Conveyor Belts are available with the below mentioned Cover Properties:

Cover Grades Applicable Standards Min. Tensile Strength (MPa) Min. Elongation at Break (%) Max. Abrasion Loss (mm³) Temperature Range
M-CFR IS-1891-Part1 24 450 150 -45oC
UAR-CFR Indus 18 400 40 -60oC
SAR-CFR Indus 18 400 90 -45oC
FR-ISO 340-CFR /DIN-K-CFR ISO-340-2013 17 400 175 -40oC
FR-ISO 340-CFR /DIN-S-CFR ISO-340-2013 17 400 175 -40oC
*MOR-CFR Indus 15 400 150 -30oC
FRX-CFR SANS-971-2013 14 400 175 -25oC

*Specifications are subject to change without notice.
